Caution! Please align security rings always in such a direction that the
flat side of the security rings point at the cam.
Fig. 20: Attaching security rings
7. Please push back the cores into the
cylinder body.
8. Please turn the cores into their initial
position and pull out keys while fas-
tening the cores.
9. Please bend the security rings gently
apart.
10. Please insert the security rings in the
respective positions.
11. Please press the security rings to-
gether with the appropriate pincers.
