Service box
DOM Sicherheitstechnik has compiled an service box for system Sigma Plus that
contains all necessary sorts of pins (body pins, core pins) as well as masterkey wa-
fers. You may order this service box directly via DOM Sicherheitstechnik. Thus you
are always well equipped with all tools and necessary pins.
Note! This service box also exists for other systems, e.g. for ix 6 KG,
Diamant, etc..
Core pins
N
N
N
N
No. 0
No. 1
No. 2
No. 3
4,85 mm
5,25 mm
5,65 mm
6,05 mm
509254 112
509255 112
509256 112
509257 112
AB
AB
AB
AB
No. 4
No. 5
No. 6
No. 7
6,45 mm
6,85 mm
7,25 mm
7,65 mm
509259 112
509260 112
509261 112
509262 112
Cam
End piece
Cam
Cam
Coupling
Coupling
half
half
standard
double entry
standard
double entry
new design
218426 008
204217
218228 008
235855 008
502154
235860
Body pins
N
N
FB
FB
No. 0, 1, 2, 3
No. 4, 5, 6, 7
No. 0, 1, 2, 3
No. 4, 5, 6, 7
5,5 mm
4,5 mm
5,5 mm
4,5 mm
509264 112
509265 112
509268 112
509269 112
H
H
H
H
No. 0, 1
No. 2, 3
No. 4, 5
No. 6, 7
5,6 mm
4,6 mm
3,6 mm
3,1 mm
509271
509272
509273
509274
Masterkey
Masterkey
Masterkey
Profile pin
Spring
Spring
Security ring
wafers
wafers
wafers
RD 2,7 x 14
V2A
0,8 mm
1,6 mm
2,4 mm
V2A
382, 393
1,0 mm
509250
509251
509252
509276
333, 555, 777
243515
202335F
242172
The box contains single compartments where you can sort in pins. The following fig-
ure shows how the wrapped pins are sorted in the service box ex works.
Note! A list of contents is part of the service box. You may make use of
the sequence of pins according to the list of contents to avoid confusion.
Note! The assembly tools may be delivered together with the service box
on your explicit order.
