Assembly / Type 777
42
Fig. 48: Positioning lock barrel
4. Please move the key gently until the
lock barrel can be inserted completely
into the padlock.
5. Please permanently protect the lock
barrel against fall out and open the
shackle.
Fig. 49: Fastening lock barrel
6. Please keep protecting the lock barrel
against fall out.
7. Please put on the screw in the
shackle opening and fix the lock bar-
rel with the screw (hand-tight).
