Page 5 of 14
2 Components
Note: The Water Chiller Tank has a capacity of 600ml and does not supply a
continuous stream of chilled water.
The unit needs time to chill the replacement water as it enters the chiller tank
as will be indicated by the Blue Indicator Light illuminating.
IMPORTANT:
Remove the filter from its packaging, lay the filter on its side in a container
and fully cover and soak the filter in cold clean water for 30 minutes to expel
all the air inside fully.
Failure to do this may cause the filter to float and not stay in its correct
position. It may also cause poor flow through the filter.
Lid
Filter – Replaceable
Upper Water Tank – Unfiltered Water 2.2L
Base Water Tank – Filtered Water 2.2L
Float Housing - Float Inside
Ring Nut
Indicator Lights
Blue ON = Water Cooling. Blue OFF = Water Cooled
Yellow On = Power Available.
Room Temperature Water Tap
Chilled Water Tap
Water Chiller Tank Inside 600ml
Cup Rest with Removable Spill Guard
