RMDT10.5(X)T Installing the refrigerator-oven combination
27
Install the condensation drain as follows:
Variant 1
➤ Run the condensation hose from the refrigerator through an opening in the floor
which goes outside under the vehicle.
Variant 2
➤ Attach the condensation hose directly to the fitting intended for it on the
ventilation grill (fig. d 4, page 12).
5.8 Install the roof vent
1. Seal the installation frame to make the connection waterproof (fig. i, page 13).
2. Insert the installation frame and screw it down tightly (fig. j, page 13). Use all
the fixing holes for this.
3. Insert the hood and screw it down tightly (fig. k, page 13).
5.9 Securing the refrigerator-oven combination
!
I
1. Move the refrigerator-oven combination into its final location.
2. Fasten the six screws (fig. l 1, page 14) through the six plastic washers in the
sides of the refrigerator, and further into the wall.
3. Put the caps (fig. l 2, page 14) onto the screw heads.
No. in
fig. h, page 13
Description
1 Hood
2 Installation frame
CAUTION!
Only screw through the receptacles provided, otherwise foamed com-
ponents, such as cables, can be damaged.
NOTE
Attach the side walls or the attached strips so that the screws are tight,
even when under increased loads (while driving).
