Page #24 background imageLoading...
Page #24 background image
EN
Using the refrigerator RMD10
24
Control
Repeatedly press until the LED indicates the desired operating mode.
Repeatedly press until the desired temperature is set.
5.5 Optional battery packs
If the vehicle’s own 12 V DC battery power supply is unavailable or if the power
supply is cut off while the appliance is in operation, the electronic control unit auto-
matically switches over to the internal battery power (if batteries are inserted).
The compartments for the battery packs (not included in scope of delivery) are
located on the right and left under the central divider between the main compart-
ment and the freezer compartment. A total of 12 AA batteries are needed.
Proceed as shown in fig. 5, page 5 to insert the batteries.
6 Using the refrigerator
A
5 Operating with AC power supply
6 Automatic mode
7 Temperature indication
8 Energy selection button
9 Temperature selection button
NOTICE!
Make sure that you only put items in the refrigerator which may be
chilled at the selected temperature.
Food may only be stored in its original packaging or in suitable
containers.
No. in
fig. 4, page 5
Description
A
MODE
MODE
50'2:(67ERRN6HLWH'RQQHUVWDJ0DL
