Dometic 459516 User Manual (English)

Other manuals for Dometic 459516

Installation Instructions24 pages

Installation & Operating Instructions15 pages

Questions and Answers:

A
Angela TerrellAug 17, 2025
Why is my Dometic 459516 Air Conditioner not maintaining the desired temperature?
- M
  Mary SmithAug 18, 2025
  Your Dometic Air Conditioner might struggle to maintain the desired temperature if the RV is gaining heat due to high outdoor temperatures or humidity. To mitigate this, park the RV in a shaded area. Additionally, use window shades, blinds, or curtains, keep windows and doors closed or minimize their use, and avoid using heat-producing appliances inside the RV. You can also operate the product in the High Fan/Cooling mode or start the product before the outside temperature increases.
E
efordAug 20, 2025
How to fix a Dometic 459516 that won't turn on?
- M
  Maria BellAug 20, 2025
  If your Dometic Air Conditioner isn't working, check if the circuit breaker has been activated and reset it if necessary. Also, inspect the fuse and replace it if it has blown.
P
Patricia Hanson MDAug 22, 2025
What to do if my Dometic Air Conditioner doesn't cool enough?
- A
  Anna SanchezAug 22, 2025
  If your Dometic Air Conditioner isn't maintaining the desired temperature, consider that the RV's heat gain could be affected by high outdoor temperatures or humidity. Try parking the RV in a shaded area. Additionally, use window shades, blinds, or curtains, keep windows and doors closed or minimize their use, and avoid using heat-producing appliances inside the RV. You can also operate the product in the Turbo Fan/Cooling mode or start the product before the outside temperature increases.
N
Nathaniel MartinezAug 26, 2025
What to do if frost forms on the evaporator coil of my Dometic 459516?
- K
  Karen Perez MDAug 26, 2025
  If you notice frost forming on the evaporator coil of your Dometic Air Conditioner, it could be due to very cold output at a very low air speed, or the outside temperature may be relatively low. First, inspect and clean the filter. Then, open the air vents and remove any obstructions. Confirm that a minimum of two distribution vents, or the quick cool vent and one vent, are open. Adjust the thermostat control knob to a warmer setting (counterclockwise). You can also operate the product on any Fan Only setting until the coil is free of frost.
S
Scott VargasAug 27, 2025
How to prevent condensation forming on ceilings from Dometic Air Conditioner?
- M
  Maria GibsonAug 27, 2025
  To reduce condensation forming on ceilings, windows, or other surfaces when using your Dometic Air Conditioner, keep doors and windows closed when the unit is in operation. This minimizes the amount of water vapor in the air that can condense on cooler surfaces.
B
brownjosephAug 30, 2025
What to do if Dometic Air Conditioner is not working when connected to land line?
- A
  Angela JenkinsAug 30, 2025
  If your Dometic Air Conditioner isn't working or is operating poorly when connected to a land line, first confirm that the land line is plugged into the power supply and that it is properly-sized for the product's power load.
K
Krista HensleySep 1, 2025
What to do if Dometic 459516 is not working when connected to generator?
- J
  James BartonSep 2, 2025
  If your Dometic Air Conditioner is not working, or working poorly, when connected to the motor generator, you should confirm the motor generator is running and producing power. Also, confirm the fuse or circuit breaker is open, ensuring the fuse is not blown, or the circuit breaker is on and not activated.
J
Jessica WaltersSep 4, 2025
What to do if my Dometic 459516 does not operate?
- A
  alec32Sep 4, 2025
  If your Dometic Air Conditioner isn't working, the circuit breaker may have activated. Try setting or resetting the circuit breaker. Alternatively, a fuse may have blown, in which case you should replace the fuse.
R
Robert PearsonSep 6, 2025
What to do if my Dometic 459516 Air Conditioner does not operate well when connected to a land line?
- E
  ehamiltonSep 6, 2025
  If your Dometic Air Conditioner isn't operating well when connected to a power supply by a land line, first confirm the land line is plugged into the power supply. Also, confirm the land line is properly-sized for the product’s power load.
P
paul64Sep 9, 2025
What to do if my Dometic Air Conditioner does not operate when connected to the motor generator?
- J
  jeremygardnerSep 9, 2025
  If your Dometic Air Conditioner is not working properly when the RV is connected to the motor generator, confirm the motor generator is running and producing power.

Dometic 459516 Specifications
