A. Table - Unit Data
Model No. Nominal
Capacity
(BTU HR)
Cooling
Electrical
Rating
Compressor
Rated Load
Amps
Compressor
Locked
Rotor
Amps
Fan Motor
Rated Load
Amps
Fan Motor
Locked
Rotor
Amps
Refrigerant
R-410A
(Oz.)
Minimum
Wire Size*
AC Circuit
Protection
***Installer
Supplied
Minimum
Generator Size**
1 Unit / 2 Units
57908.321 7,180 120 VAC
60Hz. 1PH
6.9 36.0 2.5 5.8 16.0 20 Amp 2.5 kW / 4.0 kW
57908.521 7,100 6.6 34.0 2.5 5.8 17.0 20 Amp 2.5 kW / 4.0 kW
57912.531 11,000 8.0 53.0 2.5 5.8 18.5 20 Amp 2.5 kW / 4.0 kW
57912.532 11,000 12.1 59.0 2.5 5.8 16.5 20 Amp 3.5 kW / 5.0 kW
57915.331 13,500 11.4 58.0 2.5 5.8 15.5 20 Amp 3.5 kW / 5.0 kW
57915.336 13,500 12.1 59.0 2.5 5.8 16.5 20 Amp 3.5 kW / 5.0 kW
57915.531 13,500 12.1 59.0 2.5 5.8 16.5 20 Amp 3.5 kW / 5.0 kW
57915.536 13,500 12.1 59.0 2.5 5.8 16.5 20 Amp 3.5 kW / 5.0 kW
57915.541 13,500 11.3 62.0 2.5 5.8 16.0 20 Amp 3.5 kW / 5.0 kW
57915.546 13,500 11.3 62.0 2.5 5.8 16.0 20 Amp 3.5 kW / 5.0 kW
57915.741 13,500 12.0 58.0 2.5 5.8 15.5 20 Amp 3.5 kW / 5.0 kW
57915.746 13,500 12.0 58.0 2.5 5.8 15.5 20 Amp 3.5 kW / 5.0 kW
59516.331 15,000 11.5 50.0 2.5 5.8 29.0 20 Amp 3.5 kW / 5.0 kW
59516.336 15,000 12.7 60.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
59516.531 15,000 11.5 50.0 2.5 5.8 26.5 20 Amp 3.5 kW / 5.0 kW
59516.536 15,000 11.5 50.0 2.5 5.8 29.0 20 Amp 3.5 kW / 5.0 kW
59516.731 15,000 13.3 62.0 2.0 5.6 29.0 20 Amp 3.5 kW / 5.0 kW
59530.532 N/A 8.0 53.0 2.5 5.8 18.5 15 Amp 3.5 kW / 5.0 kW
59530.536 N/A 7.8 53.0 2.0 5.6 19.0 15 Amp 3.5 kW / 5.0 kW
520310.501 9,000 7.8 49.0 3.0 8.5 20.0 20 Amp 2.5 kW / 4.0 kW
520315.501 13,500 10.3 62.0 3.0 8.5 16.5 20 Amp 3.5 kW / 5.0 kW
520315.506 13,500 10.3 62.0 3.0 8.5 16.5 20 Amp 3.5 kW / 5.0 kW
520316.501 15,000 13.2 79.0 2.8 7.6 30.0 20 Amp 3.5 kW / 5.0 kW
520316.506 15,000 13.2 79.0 2.8 7.6 30.0 20 Amp 3.5 kW / 5.0 kW
520300.501 N/A 7.8 49.0 3.0 8.5 20.0 15 Amp 2.5 kW / 4.0 kW
600312.331 11,000 9.5 53.0 3.5 10.0 17.0 20 Amp 2.5 kW / 4.0 kW
600315.331 13,500 12.4 60.0 3.5 10.0 15.2 20 Amp 3.5 kW / 5.0 kW
600315.336 13,500 12.4 60.0 3.5 10.0 15.2 20 Amp 3.5 kW / 5.0 kW
* For wire length over 24 ft., consult the National Electrical Code for proper sizing.
** Dometic Corporation gives GENERAL guidelines for generator requirements. These guidelines come from experiences
people have had in actual applications. When sizing the generator, the total power usage of your RV must be considered.
Keep in mind generators lose power at high altitudes and from lack of maintenance.
*** CIRCUIT PROTECTION: Time Delay Fuse or Circuit Breaker Required.
B. Roof Requirements
● A 14-1/4″ x 14-1/4″ (±1/8″) square opening (hereinafter referred to as “roof opening”) is required for installing this
unit. This opening is part of the return air system of the unit and MUST be nished in accordance with NFPA 1192.
● Roof construction with rafters/joists support frames on a minimum of 16 inch centers.
● Minimum of 2 inches and maximum of 5-1/2 inches distance between roof to ceiling of RV.
