Dometic B1600PLUS - Technical Data

EN
B1600PLUS, B2200, B2600 Technical data
53
15 Technical data
Dometic
B1600 PLUS
Dometic
B2200
Dometic
B2600
Item no.: 9100100007 9100100009 9102900102
Compressor cooling
capacity:
1500 W 2050 W 2500 W
Heating capacity, only in
230-V~-stationary ope-
ration:
800 W 1200 W 3300 W
Power consumption
(Cooling/Heating mode)
620 W/800 W 950 W/1200 W 1200 W/1350 W
Rated input voltage: 230 Vw / 50 Hz
Current
(Cooling/Heating mode):
2,7 / 3,5 A 4,1 / 5,2 A 5,2 /5,9 A
Necessary coverage: 4 A, inert
Operating temperature
range:
0°C to +52°C
Refrigerant: R-407C
Blower: 4 blower levels
Protection class: IP X4
Max. volume of space in
the vehicle (with insula-
ted walls):
20 m³ 25 m³ 30 m³
Dimensions L x W x H
(mm), fig. 9, page 6:
980 x 650 x 235
(height above vehicle roof)
Weight: 30kg 34kg 40,5kg
