Dometic B3000 Plus - Page 24

22
users ‘ instructions
GB
B3000 PLUS
N. DESCRPTION
1 PAN BASE
2 COVER
3 RIVETS TWO STAGE
4 VIBRATION DAMPER
5 SUPPORT
6 SUPPORT
7 COMPRESSOR
8 CAPASITOR
9 VIBRATION DAMPER
10 COMPRESSOR WIRING
11 EVAPORATOR
12 FAN
13 SOLENOID VALVE
14 RETURN PIPE
15 DELIVERY PIPE
16 LED BOARD
17 OR GASKET
18 SUPPORT
19 LABEL
20 SUPPORT
21 WIRING
22 PLENUM
23 FAN SUPPORT
24 FAN
25 RELAY BOARD
26 FILTER
27 ACTIV CARBON FILTER
28 CONDENSER
29 PIPE
30 PIPE
31 CAPILLARY TUBE
32 HEAT INSULATOR BOX
33 AIR DIFFUSER BASE
34 AIR DIFFUSER FLAP
35 GRILLE
36 DEFLECTOR SLIDE
37 KNOB
38 COVER
39 RECEIVER BOARD
40 RECEIVER COVER
41 LABEL
42 FIXING BRACKET
43 GASKET
44 GASKET
45 GASKET
46 SCREW
47 LABEL
48 EXTERNAL PROBE
49 INTERNAL PROBE
N. DESCRPTION N. DESCRPTION
Spare part list
