users ‘ instructions
5
GB
B3000 PLUS
general informations 1
Compressor (a)
Condenser (b)
Evaporator (d)
Solenoid valve (f)
condensate draining
Fan (c)
Air drawn in from outside
Air drawn in from outside
warm air
discharged
conditioned air
drawn inside
the vehicle
Air drawn in from outside
warm air
discharged
air recirculated
inside the vehicle
