Operation CF35, CF40, CF50
18
6.10 Replacing the plug fuse (12/24 V)
➤ Pull the adapter sleeve (fig. 7 4, page 5) off of the plug.
➤ Unscrew the screw (fig. 7 5, page 5) out of the upper half of the housing
(fig. 7 1, page 5).
➤ Carefully raise the upper half of the housing from the lower (fig. 7 6, page 5)
half.
➤ Take out the contact pin (fig. 7 3, page 5).
➤ Replace the defective fuse (fig. 7 2, page 5) with a new one that has the same
rating (8 A, 32 V).
➤ Re-assemble the plug in the reverse order.
6.11 Replacing the light bulb
➤ Press the switch pin (fig. 8 2, page 5) downwards so that the transparent part
(fig. 8 1, page 5) of the lamp can be removed at the front.
➤ Replace the light bulb.
I
➤ Press the transparent part of the lamp back into the housing.
NOTE
The LEDs in the light bulb must be aligned with the transparent part of
the lamp.
