EN
CFX28 – CFX65DZ Technical data
29
12 Technical data
CFX28 CFX35W CFX40W
Ref. no.: 9105306503 9105306495 9105306496
Connection voltage: 12/24 Vg and 100 240 Vw
Rated current: 12 Vg: 6.5 A
24 Vg: 3.2 A
100 Vw: 0.75 A
240 Vw: 0.32 A
12 Vg: 7.0 A
24 Vg: 3.2 A
100 Vw: 0.86 A
240 Vw: 0.42 A
Cooling capacity: +10 °C to –22 °C (+50 °F to –8 °F)
Category: 1
Energy efficiency class: A++ A++
Energy consumption: 61 kWh/annum 62 kWh/annum 64 kWh/annum
Gross volume: 28 l 34.5 l 41 l
Storage volume: 26 l 32 l 38 l
Climate class: N, T
Ambient temperature: +16 °C to +43 °C
Noise emission: 34 dB(A) 42 dB(A)
USB: 5 Vg, 500 mA
Frequency band (WiFi): 2.4 GHz
(wireless module)
2.4 GHz
RF power (WiFi): 11 0 dBm
(wireless module)
16 ± 1.5 dBm (802.11 b CCK, 11 Mbps)
12 ± 1.5 dBm (802.11 g OFDM, 54 Mbps)
11 ± 1.5 dBm (802.11 n HT20, MCS7)
Refrigerant quantity: 38 g 33 g 38 g
CO
2
equivalent: 0.054 t 0.047 t 0.054 t
Global warming potential
(GWP):
1430
Dimensions
(WxHxD) inmm
(including handles):
426 x 425 x 320 398 x 411 x 692 398 x 461 x 692
Weight: 13 kg 17.5 kg 18.5 kg
CFX-28-CFX-65--O-EN-AUSv2.book Seite 29 Dienstag, 3. April 2018 8:42 08

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dometic CFX Series and is the answer not in the manual?

Dometic CFX Series Specifications

General IconGeneral
SeriesCFX
Power Source12/24V DC, 100-240V AC
RefrigerantR134a
TypePortable Freezer
CategoryFreezer
Temperature Range+10°C to -22°C (+50°F to -7.6°F)
Energy ConsumptionVaries by model
FeaturesDigital temperature control, Battery protection system
InsulationHigh-efficiency insulation
CapacityVaries by model
WeightVaries by model
DimensionsVaries by model
MaterialPlastic, Metal
