Dometic CFX3 Series Installation Manual

5
EN
CFX3 Protective Covers Installation
4. Begin fitting the next molded panel onto the opposite
end of the cooler by starting the zipper: attach the
zipper between the so cover and the molded panel,
then pull the zipper down a short distance.
5. Finish fitting the molded panel to the cooler.
6. Fully close the zipper.
7. Fully close the zipper on the display end.
3.3 Placing the Lid Cover
Use this section to find instructions for placing the lid
cover on a specific CRX3 cooler model.
3.3.1 For CFX3 35 and CFX3 45 Coolers
w
q
8 Removing the Lid Gasket (CFX3 45 shown)
q
Cooler Lid
w
Lid Gasket
1. Gently pull out the lid gasket on the two long sides
of the lid.
e
w
q
9 Attaching the Lid Cover
q
Lid Cover
e
Gasket Groove
w
Lid Cover Hook
2. Position the lid cover in alignment with the latch
clearance slot.
3. Insert the lid cover hooks into the gasket groove.
4. Refit the lid gasket, pushing it fully into the groove.
3.3.2 For CFX3 55 and CFX3 100 Coolers
q
w
10 Removing the Lid Gasket (CFX3 55 shown)
q
Cooler Lid
w
Lid Gasket
1. Gently pull out the lid gasket on the two short sides
of the lid.
e
w
q
11 Attaching the Lid Cover
q
Lid Cover
e
Gasket Groove
w
Lid Cover Hook
2. Position the lid cover so that the Dometic logo
direction matches the cooler Dometic logo
direction.

Dometic CFX3 Series Specifications

General

Power Source	12/24V DC, 100-240V AC
Refrigerant	R134a
Product Description	Portable Refrigerator/Freezer
Temperature Range	-22°C to +10°C
Insulation	High-performance polyurethane foam
Digital Display	Yes
Connectivity	WiFi and Bluetooth
App Compatibility	Dometic CFX3 App
Color	Gray
Capacity	Varies by model (e.g., 35, 45, 55, 75, 95 liters)
Weight	Varies by model (refer to product specifications for specific weight)
Dimensions (W x H x D)	Varies by model (refer to product specifications for specific dimensions)
Certification	CE, RoHS
Warranty	3 years
Material	ExoFrame construction with fender frame protected edges
