CS-NC15, CS-NCVM Installing the cooling unit
13
7 Installing the cooling unit
7.1 Tools required
For installation and assembly, you will need the following tools:
•
Drill
•
Screwdriver
•
Open-ended spanner: 16 mm, 19 mm and 21 mm
•
Sealant and PUR foam
•
Cable, cable lugs and cable clips
7.2 Notes on the cooling container
Permitted cooling area contents
Make sure that maximum cooling area contents specified are not exceeded for the
respective vaporiser type (see chapter “Technical data” on page 20).
Minimum insulation
The maximum cooling area contents are based on a minimum insulation thickness of
35 mm of foam polyurethane with a density of 40 kg/m³. If other insulating materials
are used such as styrofoam, double the wall thickness to attain the same level of heat
insulation.
Keys for the illustrations
No. in fig. 1,
page 3
Explanation
1 DC fan
2 Thermostat button
3 Connection plug for DC fan
4 Thermostat
5 Connection cable
CS-NC15_CS-NCVM--IO--16s.book Seite 13 Dienstag, 9. Oktober 2018 5:24 17
