Installing the cooling unit CS-NC15, CS-NCVM
14
A
7.3 Installing the cooling unit
It is important to select the proper location for setting up the unit. To ensure trouble-
free operation, please note the following points:
•
Set up the cooling unit in a dry, sheltered place. Avoid placing it near heat
sources such as radiators, gas ovens or hot water pipes. Do not place in direct
sunlight.
•
On a boat, install the cooling unit, if possible, below the waterline.
•
The refrigeration unit functions at a short-term inclination of up to 30°. Install the
unit on a flat base.
•
The cooled air must dissipate unhindered (fig. 3, page 5).
•
When installing the cooling unit in a closed room such as a wardrobe, pantry or
aft compartment, openings must have a cross section of at least 200 cm²
(25cmx8cm) for cooling and exhaust air.
•
Make sure that the air flow on the condenser (fig. 3, page 5) is not restricted.
•
Maintain a minimum distance between the condenser and adjoining wall of
50 mm.
Observe the drilling template (fig. 4 , page 6) and the installation drawing (fig. 5,
page 7).
No. in fig. 2,
page 4
Explanation
1 Connection cable
NOTICE!
Carefully insulate and seal off the wall openings after installation to
prevent moisture penetration.
