DC-Kit2 Installing and connecting the DC kit
15
Observe the following safety instructions for the electrical connections:
A
Observe the following instructions when selecting the location for installing the
components:
• Make sure the cables are of the correct length.
• Choose a well-ventilated installation location near the supply battery.
7.1 Preparing the installation
➤ Disconnect the following voltage supplies in the vehicle:
– Positive battery terminal
– External voltage supply
NOTICE! Risk of short circuit!
• First, disconnect the 230 V external power supply to the caravan.
• Disconnect the earth connection to the supply battery.
• Disconnect the connection to the starter battery.
• If you have to feed cables through metal walls or other walls with
sharp edges, use ducts or tubes to prevent damage.
• Do not lay cables which are loose or bent next to electrically
conductive material (metal).
• Fasten the cables securely.
• Ensure the 12 V cables are especially well-protected.
• Check whether you need to fit any additional fuses.
• Do not pull on the cables.
• Do not lay the 230 V mains cable and the 12/24 V DC cable in the
same duct.
• Lay the cables so that they cannot be tripped over or damaged.
DC-Kit2--IO-16s.book Seite 15 Dienstag, 21. März 2017 2:15 14
