FreshLight Installation
15
Connecting the air outlet unit with the roof air conditioner
See fig. d
➤ Remove the premounted filter covers (1).
➤ Remove the premounted air filter (2).
Fitting the seals
See fig. e
➤ Fit the seals (1).
Determine the thickness by referring to the following table:
Connecting the circuit board
See fig. f
➤ Insert the 12-pin plug (1) in the socket (4) on the circuit board of the air outlet unit.
➤ Insert the 2-pin plug (2) in the socket (3) on the circuit board.
Ceiling thickness Seal thickness
25 mm 20 mm
25–30mm 25mm
30–35mm 30mm
35–40mm 35mm
40–45mm 40mm
45–50mm 45mm
50–55mm 50mm
55–60mm 55mm
