Heki2 Installing the Heki2
7
7Installing the Heki2
Supplementary to fig. 4
The scope of delivery includes a mounting frame, which is suitable for roof thick-
nesses of 25 – 32 mm. For roof thicknesses of 33 – 60 mm, you need to have a
suitable mounting set (see table).
➤ Measure your roof thickness W.
➤ Choose a suitable mounting set:
See fig. 5
➤ Check that the roof light has sufficient space around it (approx. 1 to 2 mm) in the
roof opening.
See fig. 6
➤ Clean the roof opening in the mounting area.
See fig. 7
A
➤ Seal the mounting frame with a flexible non-hardening sealing compound (e.g.
SikaLastomer-710).
Roof thickness
Mounting bracket
colour
Screws Item no.
25 – 32 mm Grey ∅ 4 x 25 mm Included in the
scope of delivery
33 – 39 mm Black ∅ 4x32mm 9104100245
39 – 46 mm Yellow ∅ 4x40mm 9104100246
46 – 53 mm Blue ∅ 4x46mm 9104100247
53 – 60 mm Red ∅ 4x52mm 9104100248
NOTICE!
Observe the instructions of the sealant manufacturer.
