Dometic MANUAL REFRIGERATOR Service Manual

(31)
Let’s look at the current Dometic refrigerators
and see how the gas flows.
(32)
Gas flows from the gas line to the shut-off valve
and to the connection piece.
(33)
into the combination gas and electric thermostat
(34)
through the safety valve thermocouple
(35)
test housing
UNDERSTANDING
THE
GAS SYSTEM
SHUT-OFF
VALVE
I
GAS LINE
CONNECTION
PIECE
COMBINATION
GAS & ELECTRIC
THERMOSTAT
SAFETY VALVE/
PRESSURE
TEST
HOUSING
D-6-12
