There are 3 screws in the burner area that
must also be removed. Please note
-
these are
machine screws, not sheet metal type. It is
important for them to be reinstalled in this area
only.
(56)
The control assernbly will now drop down and
can be pulled out..,.,
fnr
On the present line of manual refrigerators we
use one of two methods of igniting the burner
flame. Shown on the right is the piezo system;
on the left is the igniter reigniter.
(58)
The piezo lighter is a self-contained assembly
which generalty -does not need maintenance.
When the button is ‘pushed,
a
spring loaded
striker creates a spark. If
there is
no resistance
when pressing the button, the
piezo
igniter is
defective and must be replaced. If the
piezo
snaps or has resistance when the button is
pushed, but there is no spark, the problem lies
in the electrode or electrode wire.
D-6-16
