11. Loosen band clamp on discharge loop outlet and remove discharge adapter tting/hose
tting assembly (g.
13
).
12. Lubricate discharge tting assembly and inside end of discharge hose with liquid dishwashing
soap. Push discharge tting assembly into discharge hose and connect with two hose clamps.
Be sure to position hose clamp screws 180° apart from each other (g.
14
). Place toilet near
access holes and oor brackets.
13. Connect toilet water line and 4-pin connector to water supply line and control module cable.
14. Position toilet over oor brackets and tilt toilet up from back. Push discharge assembly tting
and hose up into discharge loop outlet. Lower toilet to oor and tighten band clamp (g.
15
).
15. Turn on water supply and electrical power to toilet, and check for leaks. Press “Flush” switch
(g.
4
2, page 2). If leak occurs, tighten connection.
16. At oor mounting holes, drill pilot holes for hex-head oor fasteners. Install fasteners and
washers using a 3/8 in. (10 mm) socket wrench (g.
16
).
17. Cover oor fasteners with plastic covers (g.
17
).
