Intended Use MCS T6, MCS T12, MCS T16
16
5 Intended Use
The Marine Climate System MCS T is an air conditioning system designed for use
on boats or yachts. It can cool down or warm up the interior of the vessel.
6 Technical Description
The Marine Climate System MCS T marine air conditioner is designated to run on
230 Vw.
The Marine Climate System MCS T kit consists of the following components:
•
DTU self contained A/C unit
•
Control panel and display cable
•
Ducting
•
Supply-air grille
•
Return-air grille
•
Seawater pump
•
Strainer
•
Speed scoop thru-hull
•
Overboard discharge fitting
•
Seawater hose
•
Fittings for pump and strainer
The system is a seawater cooled air conditioning system.
6.1 Components of the Marine Climate System MCS T
MCS T16 only:
The DTU unit T16 is supplied with a 7" duct ring.
➤ Replace the 7" duct ring with the 6" duct ring using the 4 rivets supplied
(fig. 2, page 3).
Item in
fig. 1, page 3
Description
1Duct ring
2Mounting bracket
3 Condensate drain (two of three locations shown)
4 Composite base pan
5 Rotary compressor
6 Rotable blower assembly
MCS-T6-T12-T16--I-16s.book Seite 16 Dienstag, 14. November 2017 11:09 11
