MD310, MD390, MD450 Installing safe
9
• Avoid damp ambient conditions (e.g in the bathroom and swimming pool) in
order to avoid condensation forming in the device.
• Select a fastening material (screws with plugs, if necessary) which is appropriate
for the base.
7.2 Attaching the safe
➤ Select a suitable installation location.
➤ Select an appropriate method for installation (attachment on the rear or on the
underside).
➤ Mark the drill holes according to the table below
Drilling on the rear (fig. 2, page 3)
Drilling on the underside (fig. 3, page 3)
➤ Pre-drill the hole in the mounting location (e.g. in the wall or cupboard).
➤ Attach the safe with a suitable fastening material.
Model MD450 MD390 MD310
H 100 mm 100 mm 82.5 mm
L1 120 mm 90 mm 50 mm
L2 210 mm 210 mm 210 mm
Model MD450 MD390 MD310
L1 120 mm 90 mm 50 mm
L2 210 mm 210 mm 210 mm
P 200 mm 235 mm 117.5 mm
