PI8022, PI8023, MO9722 Using the device
19
Te st p o i n t
A
The test point is supplied loose with the device.
1. Remove one burner head and its injector.
2. Screw in the test point fitting.
3. Measure the pressure with the corresponding burner gas valve on high flame
and with an inlet pressure of 2.75 kPa.
7 Using the device
7.1 Igniting a burner
!
A
NOTICE! Damage hazard
The burner and its bottom are made of aluminum. The fixing screws are
made of stainless steel. Do not loosen the screws in hot conditions as
you may damage the screw hole of the aluminum components.
WARNING! Beware of injury!
The complete ignition process must be visible from above and must not
be hidden by pots placed on the stove.
NOTICE! Damage hazard
The flame must not extend beyond the edge of the pot. Centre the pot
above the burner ensuring stability on the pot grid (see fig. 1, page 7).
