6
INSTRUCTIONS FOR USE
STARTING THE REFRIGERATOR
FIRE HAZARD. When the RV has not been
used for some time, make sure that the path
between the burner jet and the burner tube
has not been obstructed before lighting the
LP gas burner. Failure to obey this warning
could cause a re resulting in death or seri-
ous injury.
FIRE OR EXPLOSION HAZARD. When refuel-
ing or parked near gasoline pumps shut off all
LP gas appliances. Failure to obey this warn-
ing could cause a re or explosion resulting
in death or serious injury
LP GAS EQUIPMENT ASSEMBLY
1. Check that all the manual gas valves are in the
ON position.
2. Make sure that a continuous 12 VDC supply is
available for the electronic control to function.
3. Press the ON/OFF button.
4. Select operation mode:
- AUTO - AES/AUTO mode (AC and Gas)
Press the AUTO/GAS - AES/AUTO/Gas mode
selector button (if not already on). The illumi-
nated lamp indicates the selected mode.
(If the CHECK indicator lamp is illuminated,
see REFRIGERATOR OVERVIEW > MODES
OF OPERATION > AUTO MODE - AES/AUTO
MODE for further information.)
- GAS mode (LP gas operation only)
Press the AUTO/GAS - AES/AUTO/Gas mode
selector button to turn off the AUTO mode (if
not already off).
(Within 45 seconds the burner should be ig-
nited and operating normally. If not, see RE-
FRIGERATOR OVERVIEW > MODES OF
OPERATION > GAS MODE for further infor-
mation.)
- DC mode (3-way models only)
Press the DC mode indicator button. The DC
lamp will be turned on. To select AUTO or GAS
mode, turn off the DC mode by pressing the
DC mode selector button. The DC lamp will
then be turned off.
ADJUSTING THE THERMOSTAT
RM2354, RM2454, RM2554, DM2662, DM2663, DM2862
& NDM1062
The thermostat controls both the gas and electric opera-
tion, thereby eliminating the necessity of resetting each
time a different energy source is employed. After the initial
start-up, the thermostat should be adjusted to the desired
temperature setting.
1. Press the temperature selector button until the
lamp at the desired setting is illuminated.
RM2351, RM2451, RM2551, DM2652 & DM2852
The temperature is controlled by a factory preset temper-
ature setting.
COLD WEATHER LOW AMBIENT
CONTROL
NDM1062
The refrigerator is equipped with an exclusive feature that
allows for trouble-free operation in low ambient tempera-
ture (like below 50°F) for extended periods of time. Once
the outdoor temperature is above 50°F, the low ambient
switch should be turned off.
1. Turn the Low ambient control switch to I (ON).
2. Press the LAC button. The indicator lamp will
illuminate.
The Low ambient control
switch is located beneath
the top decoration panel
that houses the control
panel.
ON
OFF
AC
GAS
CHECK
AES
AUTO
COLD
1
2
3
4
5
COLDEST CLC
LAC
INLET FITTING
MANUAL SHUTOFF VALVE
Shown in open position
PRESSURE TEST PORT
BURNER JET
BURNER TUBE
SPARK ELECTRODE
BURNER MOUNTING SCREWS
SOLENOID VALVE
