Dometic Penguin II User Manual

7
EN
Value Air Distribution Box (ADB), Mechanical General Information
3.4.5 High Performance
q
r
i
u
t
y
w
e
6 High Performance (540315, 540316)
q
13.0 in. (330 mm)
y
Front of Unit
w
39.6 in. (1006 mm)
u
18.0 in. (457 mm)
Clearance
e
29.9 in. (760 mm)
r
Center Line of Unit
i
Air Flow
Clearance Area
(Shaded)
t
Roof Opening
3.4.6 Penguin
q
r
o
u
i
u
t
y
w
e
7 Penguin (640312, 640315)
q
9.5 in. (241 mm)
u
4.0 in. (102 mm)
Clearance
w
40.0 in. (1016 mm)
e
29.0 in. (737 mm)
i
12.0 in. (305 mm)
Clearance
r
Center Line of Unit
t
Roof Opening
o
Air Flow Clearance
Area (Shaded)
y
Front of Unit

Dometic Penguin II Specifications

General

Hertz	60 Hz
Installation Type	Rooftop
Cooling Capacity	13, 500 BTU/h
Control Type	Digital
Power Source	115V AC
