Connecting the awning (PW1500 and PW1750) PerfectWall
12
7Connecting the awning (PW1500 and
PW1750)
!
A
There are two options for the electrical connection of the awning:
Awning switch with an integrated main switch
Main switch and receiver for the remote control
Observe the following installation instructions:
Fit the supplied main switch and fuse (15 A) to the positive line of the power
supply. The main switch is required to switch off the awning when side walls are
fitted to the awning, for example, or if the vehicle is taken out of service for an
extended period of time (otherwise the standby consumption may drain the
battery).
Install the receiver on the inside of the vehicle to protect it from moisture.
Observe the length of the cable between the awning motor and receiver when
choosing a place to install it.
Do not shorten the antenna cable.
When installing the supplied plug, use a suitable tool (crimping tool) to ensure
that the connection is secure and durable.
If you want to connect an awning light (accessory), make sure that its maximum
power consumption is 30 W. When connecting, make sure the polarity is
correct.
WARNING!
Connect the ignition (D+ signal) to the orange line of the receiver.
This is the only way to ensure that the awning cannot be opened
while driving.
Only use the original remote control supplied and optional original
wall switch.The use of original parts is the only way to ensure that
with connected D+ signal the power supply is disconnected and the
awning cannot be opened while driving.
Disconnect the power supply before starting the assembly.
Only permit a qualified electrician to connect the awning to the elec-
trical power.
CAUTION!
The cables and cabinets in the interior of the vehicle must not be
damaged through drilling the holes.
