15
Manual energy selection / automatic ignition (RM 8xx1) MES:
123
4
567
Mode
Fig. 10
Automatic energy selection / automatic ignition (RM 8xx5) AES:
1 = Power On switch / Energy selector switch (MODE)
2 = Temperature selection
3 = Door opening (only when equipped with electrical door lock)
4 = Indicator LED failure
5 = Indicator LED door lock (optional)
6 = Indikator-LED / operating mode display
7 = Temperature level display
Fig. 11
123
4
567
Mode
Explanations:
Switch the refrigerator ON or OFF by pressing
button "1" for 2 seconds.
Button "1" allows you to either initiate the
requested energy supply or activate dimming
of the LED brightness. By pushing once, the
indicators illuminate for 10 seconds.
Button "3" and indicator "5" constitute an
optional feature available with refrigerators
equipped with electrical door locking (
see also
section 5.3 Door lock
).
Refrigerator operation
