INSTALLATION INSTRUCTIONS
CHANGING DOOR SWING
To change the door swing to the opposite side:
Remove the top hinge pin and lift out the door.
Save the pin.
Remove the lower hinge pin.
Move the hinge pin to the hinge bracket on the op-
posite side of the refrigerator.
Remove the hinge bushing and the latch retainer
on the top of the door. Save the screw to the latch
retainer.
Take a new hinge bushing and latch retainer (from
the parts bag placed inside the refrigerator).
The bushing and the latch retainer on the top of
the door should be shifted. Use the same screw to
fasten the latch retainer.
Remove the travel catch on the upper hinge
bracket. Save the screw; re-fasten it on the hinge
bracket at the opposite side.
The lower hinge bracket that is not in use can be
removed and the screw holes covered by plastic
plugs (from the parts bag).
Put the door on the lower hinge pin and close the
door. The door gasket keeps the door in position.
Replace the top hinge pin.
Check the travel catch to make sure it works prop-
erly, that the door closes easily and that the gasket
seals well on all sides.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
MOUNTING THE DOOR PANEL
The refrigerator is normally delivered without door panel
and it is advisable to mount the panel before the refrigerator
is installed in the enclosure. The lower decoration strip and
parts bag are taped inside the door.
Before starting the mounting work, read this instruction thor-
oughly and check that the panel dimensions are in compli-
ance with those given in the following table:
PANEL DIMENSIONS
Max thickness 5/32 (4 mm)
Height Width
max min max min
inch 26-17/64 26-3/16 19-5/8 19-17/32
mm 667 665 498 496
To mount the panel, follow these steps:
Slide the panel from the bottom of the door into
the grooves on the vertical edges of the door .
Push the panel upwards.
Take the two plastic panel stops from the parts bag
and put them in the two holes at the lower door
frame.
Put the decoration strip across the door and fasten
it with three screws from the parts bag.
REFRIGERATOR REMOVAL
Before working on the refrigerator, make sure the
230- 240 V AC voltage and 12 V DC voltage leads
are disconnected.
Shut off the gas supply at the LP tank.
Disconnect the gas supply line.
Always use a back up wrench when loosening and
tightening connections.
Cap the gas supply line, loosen the screws anchor-
ing the refrigerator to the enclosure and slide the
refrigerator out of the compartment.
When replacing the refrigerator make sure that the
sealing strips are properly positioned.
Replacement is the reverse of removal. Check all
connections for gas leaks.
1.
2.
3.
4.
1.
2.
3.
4.
5.
6.
