- 15 -
INSTALLATION PROCEDURE
RM2451, RM2454, RM2551, RM2554,
DM2652, DM2662, DM2663, DM2852,
DM2862, RM3762, RM3962, RM1350,
NDA1402 & NDM1062
Install the screws in the following order:
1. TWO SCREWS INSTALLED THROUGH THE
FRONT BASE.
The refrigerator is provided with a lower front strip
(shipped as a loose part). Attach the front strip after
the refrigerator is set into the cutout opening.
a) Install the lower front strip by sliding it under the
bottom hinge plate(s).
Models with 1 Hinge Plate
The hinge plate can be located on
the left or right side depending
on the door swing. Slip under the
hinge and swing into place.
Models with 2 Hinge Plates
Models with 2 Hinge Plates
One screw through each hinge.
b) Secure the refrigerator and the lower front
strip with two screws.
Models with 1 Hinge Plate
One screw through the hinge and
on the opposite side and then, one
screw through the lower front strip.
To Next Page
