- 25 -
5. Put back the decoration strip. Slide (A) or
snap (B) into place.
6. Slide the handle into place (A) and attach with
the screw (B).
INSTALLATION PROCEDURE
DOOR PANEL INSTALLATION CONT'D
RM1350
To install the door panels, follow these steps:
1. Open the door.
2. Remove the screw (A). Slide off the handle (B).*
3. Slide off the decoration strip.
4. Insert the door
panel’s edges into
the grooves of the
door frame.
Push the panel side-
ways until the edge
of the panel is tted
into the opposite side
groove.
* For RM1350WID it is not necessary to
remove the right freezer door handle in
order to mount the door panel.
A
B
A
B
A
B
To Next Page
