Scope of delivery RTX1000/2000, SPX1200T
6
4.1 RTX1000, RTX2000
The installation kit enables the installation of a CoolAir RTX1000 or RTX2000
parking cooler in a roof ventilation opening (hatch) provided at the plant in a
lveco Stralis Hi-Street/Hi-Road (high roof) or lveco Stralis Hi-Way (high roof)
driver cab.
4.2 SPX1200T
The installation kit enables the installation of a CoolAir STX1200T roof evaporator
in a roof ventilation opening (hatch) provided at the plant in a lveco Stralis
Hi-Street/Hi-Road (high roof) or lveco Stralis Hi-Way (high roof) driver cab.
5 Scope of delivery
CoolAir RTX1000, RTX2000/SPX1200T installation kit for
lveco Stralis Hi-Street/Hi-Road
Item in
fig. 1
Part designation Quantity
. Thread insert with flange M8 (RTX only) 12
3 Spacer sleeve L = 18 mm, ∅ 14 mm 12
$ Washer 8.5 x 20 12
/ Spring washer M8 12
1 Hex screw M8 x 45 12
4 Cover frame Iveco 1
2 2.5 m insulating tape (profile: 10 x 20 mm) 1
( Connection cable 6 mm² x 11 m 1
, Cable binder 1
" Maxi Fuse 40 A 1
Maxi Fuse holder (40 A) 1
Ring terminal 6 mm², M8 1
Ring terminal 6 mm², M10 1
Joint connector 6 mm² 1
Blade fuse, 2 A 1
Fuse holder (2 A) 1
Ring terminal 0.5 mm², M8 2
Joint connector 0.5 mm² 1
1/4" hexagon bit 1
– Installation manual 1
