EN
Installation RTX1000/2000, SPX1200T
12
6.8 Installing supply lines to the condenser unit
(SPX1200T only)
Observe the following instructions when installing the supply lines:
Also observe the installation instructions for the condenser unit.
The maximum cable length between the evaporator and condenser unit is
4.20 m (fig. d).
When installing and bending supply lines, avoid narrow radii. Use a suitable
round object as a bending aid. A radius which is too narrow will buckle the
refrigerant line, and the parking cooler will be inoperable.
Shorten any supply line which is not needed by bending a curve.
Apply packing compound (fig. d 1) to prevent water entering between the
rear wall of the truck and the clip.
I
Fasten the supply lines to the rear wall of the truck using the clips provided
(fig. d).
Insert the corrugated piping in the holder provided (fig. d ).
Put the cover on (fig. d ).
6.9 Fixing the cover frame
A
Fix the cover frame in place as illustrated (fig. c).
The cover frame is fixed in the same way as the original sunroof cover frame.
NOTE
If you wish to avoid damaging the rear wall of the truck (drilling a hole), you can
also apply the clip using a suitable adhesive. Observe the instructions provided
by the adhesive manufacturer.
NOTICE!
Tighten the screws carefully in order not to damage the cover frame.
57;63;7,YHFR,VERRN6HLWH)UHLWDJ'H]HPEHU

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dometic RTX2000 and is the answer not in the manual?

Dometic RTX2000 Specifications

General IconGeneral
Dimensions720 x 259 x 400 mm
Weight20.9 kg
Operating ModesCooling
Voltage12 V
RefrigerantR134a
Input Voltage12 V
Suitable forTrucks
Power SourceBattery
