Scope of delivery RTX1000/2000, SPX1200T
6
I
4.1 RTX1000, RTX2000
The installation kit enables the installation of a CoolAir RTX1000 or RTX2000
parking cooler in a roof ventilation opening (hatch) provided at the plant in a Sca-
nia (Highline and Topline) driver cab.
4.2 SPX1200T
The installation kit enables the installation of a CoolAir STX1200T roof evaporator
in a roof ventilation opening (hatch) provided at the plant in a Scania (Highline
and Topline) driver cab.
5 Scope of delivery
CoolAir RTX1000, RTX2000/SPX1200T installation kit for
Scania Highline and Topline
NOTE
For cabs with a mechanical ventilation hatch two holders (Scania no.
1533737), which are standard with the electrical ventilation hatch, are still
needed to fix the parking cooler.
Item in
fig. 1
Part designation Quantity
. Thread insert with flange M8 (RTX only) 6
3 Spacer sleeve L = 48 mm, ∅ 14 mm 6
$ Washer 8.5 x 20 6
/ Spring washer M8 6
1 Hex screw M8 x 65 6
4 Spacer sleeve L = 30 mm, ∅ 10 mm 4
2 Cover frame Scania 1
( Washer M6 4
, Allen screw with cylindrical head M6 x 45 4
" 2.5 m insulating tape (profile: 10 x 20 mm) 1
 Connection cable 6 mm² x 4 m 1
 Cable binder 1
 1/4" hexagon bit 1
– Installation manual 1
