Technical data TEC60EV
26
14 Technical data
This CO
2
measurement results from testing over a fixed test cycle under laboratory
conditions a(n) (parent) engine representative of the engine type (engine family) and
shall not imply or express any guarantee of the performance of a particular engine.
TEC60EV
Ref. no.: 9102900303
Rated output voltage: 230 Vw / 50 Hz
Max. constant output
(at 25 °C at sea level):
6200 W
Battery charger output voltage: 12 Vg
Battery charger max. output
current:
30 A
Operating temperature range: –15 °C to +50 °C
Total harmonic distortion: <3 %
Fuel: RON 91 regular grade petrol
Consumption: max. 3.7 l/h
Motor output: 6.6 kW (8.9 PS)
Max. revolutions per minute:
3600 min
–1
Motor oil: 1.1 l
CO
2
value 743 g/kW-hr
Sound level: 91 dB(A)
Sound level at distance of 7 m: 66 dB(A)
Dimensions: see fig. 9, page 5
Weight: 110 kg
Inspection/certification:
TEC60EV-O-16s.book Seite 26 Montag, 5. August 2019 12:56 12
