INSTALLATION INSTRUCTIONS
NOTICE! Risk of damage to appliance or surround-
ings. Review and follow all safety and installation
instructions during installation.
A. Select the Location
Before installing the appliance, select a location
that adheres to the following criteria:
1. A rigid, dry, and level surface removed from di-
rect sunlight.
2. Proper ventilation
3. Room temperature must be above freezing
(32°For0°C).
4. Isolated from heat sources
NOTE: Ensure the appliance does not rest on its
power cord. It is recommended the appliance is
notinstalledonanysoftoorsurfaces.
B. Connect the Inlet Hose
1. Connect the inlet hose as indicated in the
gure.Connectthehosestothehotwatertaps
as indicated.
NOTE: Do not over-tighten the hoses. If there is
anyleakageafterconnection,conrmthehose
end has a rubber “O” ring and repeat the steps
to connect the inlet hose.
2. Connectthettingtothetapandfastenitclock-
wise.
3. Connect the opposite end of the hose to the
inlet valve on the backside of the appliance.
C. Drain System Options
● The standpipe drain system may be installed in the
wall(Fig.6)oroor(Fig.7).Thedrainrequiresamin-
imum inner-diameter standpipe of 2 inches (5 cm).
● The minimum carry away capacity of the drain can
be no less than 17 gal (64 L) per minute. The top
of the standpipe MUST be between at least 23.6
inches (60 cm) and 39.4 inches (100 cm) above
the bottom of the appliance.
● The laundry tub drain system (Fig. 8) requires a
minimum 20 gal (76 L) capacity. The top of the
laundry tub MUST be a minimum of 23.6 inches
above the oor but no more than 39.4 inches.
● The oor drain system (Fig. 9) requires an air
gap and siphon break that MUST be purchased
separately. The siphon break MUST be a mini-
mum of 23.6 inches (60 cm) from the bottom of
the appliance. Additional hoses may be needed.
60
(100 cm)
23.6”Max 39.4”
FIG. 4
FIG. 5
FIG. 6
FIG. 7
FIG. 8
