25
To scanner head
Power supply LED on the
front of the laser unit.
Shutter LEDs on the front of the laser unit
(only with shutter option)
Illuminates when shutter is open
Shutter LED
Power supply LED on the
front of the laser unit.
To scanner head
Laser Module without Shutter Option
Laser Module with Shutter Option
