Setting Name Explanation
Source ID Select the name of the element that will be referenced.
Source oset Add an oset to the referenced data.
Source length Set the maximum length of the referenced data.
8.
Select the green Tick icon to confirm the settings.
9.
Select the green Tick icon to add the element to the label design.
10. In the label design area, select the reference element.
11. In the label creator's side menu select the Element tab.
12. Select the Edit menu.
13.
Use the settings in the edit menu to define the element's visual appearance.
14. Select the Save icon to save the change.
End of procedure.
Add Script Element
Script elements written in Lua programming language can be imported into the controller using
the file manager, see Label Store and File Management on page 167. Once imported, the script
element can then be added into the label design.
Note When positioning the element in the label editor, be aware that the length of the
printed data may exceed the bounding box of the element.
To add a script element into the label design:
1. In the Side menu select the Element tab.
2. Select the Add menu.
3. Select Text or Barcode.
Note If Barcode is selected, define the barcode type and barcode settings.
4.
Select +Variable at the top of the screen.
5.
Select Insert new...
6.
Select Script.
7.
Select Source.
8.
Navigate to the location of the script file and select it.
9.
Select the green Tick icon to confirm the correct script file has been selected.
10.
Select the green Tick icon to confirm the settings.
11.
Select the green Tick icon to add the element to the label design.
12.
In the label design area, select the script element.
13.
In the label creator's side menu select the Element tab.
OPERATION
EPT053091 - Issue 5 - 07 May 2021 150
