EPT062879 Issue 3 January 2021 9
Electrical Hazards
System Controller
SPECIFICATION
Note: The controller and the inspection system contain no user serviceable components
and should not be opened.
WARNING: Danger of electrocution.
• The R-Series Vision System Controller is powered by a brick
PSU. Any isolator switch must be in easy reach of the
operator.
• No user serviceable parts are inside the R-Series vision
system controller or the inspection system and therefore they
must not be opened.
Temperature Range
Working:
5 to 45°C
Controller IP rating: IP20
Note: The controller must be located in a suitable
environment compatible with the IP rating.
Dimensions: 20mm (W) x 114mm (L) x (D) 47mm (D)
Standard Finish: Aluminium
Weight: 0.68Kg
Temperature range
(Storage):
-40 to 85°C
Humidity (Operating): 5 to 90% RH
Electrical Supply: 115 - 230 Vac, 47 - 64Hz
Power: 30VA
