16 EPT062879 Issue 3 January 2021
Log Files
Log files can be found at:
C:\Users\Public\Documents\MultiScan3\logs
The files are date stamped and contain addition useful information for fault finding.
(6) Network Connection Displays external connection of the Network if
connected. If not connected it will report that no
connections are set up (this connection does not
apply to the inspection system connection).
(7) Pause Settings Set up the pause conditions.
(8) Pause Pause the image and the result log.
(9) Result Log Rolling display of the result for each inspection.
(10) Settings Press the Settings button to modify the area of
inspection.
(11) Home Press HOME to return to the home screen.
(12) Inspection information Summary information for each inspection tool.
(13) Job Information Displays summary report of inspection job.
(14) Inspection system Displays inspection system image and inspection
information.
(15) Mode Selection (Not
displayed)
In operator mode this allows for new jobs to be
selected and allows the exit of the program.
