EN
INFORMATION MODE
The console features an information mode that allows you to
enable or disable the demo mode and choose between kilometres
and miles for the unit of measurement. The information mode
also keeps track of information regarding use of the treadmill.
To select the information mode:
- Press and hold the «STOP» button.
- Insert the safety key in the console then let go of the «STOP»
button.
Demonstration mode:
The console includes a demo mode that is used when the
treadmill is displayed in store.
When demo mode is activated, and when the power cable is
plugged in, the switch is in the reset position and the safety key
is in the console, the console works normally.
When you remove the safety key, the screens stay lit up but the
buttons don’t work.
When the demo mode is activated, the left-hand screen shows
a «d».
To enable or disable the demo mode, press the reduce speed
button.
Choosing the unit of measurement for speed and distance:
The left-hand screen shows an «M» for kilometres or an «E» for
miles.
To change the unit of measurement, press the increase speed
button.
Instructions for using the treadmill:
For a few seconds, the right-hand screen displays the treadmill’s
total number of hours of use as well as the total number of
kilometres or miles run by the treadmill.
To exit information mode, remove the key from the console.
TROUBLESHOOTING
The treadmill won’t switch on:
1 - Check that the power cable is plugged into a working wall
socket (to check if the wall socket works, plug in a lamp or
other electrical appliance).
2 - Check that the power cable is plugged into a properly earthed
wall socket. If you need an extension cable, only use a 1 mm²
(size 14) 3 conductor cable that is no longer than 1.5m (5ft).
3 - Having connected the power cable, make sure that the key is
properly inserted in the console.
4 - Check the switch on the treadmill frame, near the power
cable. If the switch is sticking out, as illustrated, the switch has
tripped. To turn the switch back on, wait 5 minutes then press
the switch.
The treadmill turned itself off during use:
1 - Check the switch (see diagram below). If the circuit breaker
has tripped, wait 5 minutes then press the switch.
2 - Make sure that the power cable is plugged in.
3 - Remove the key from the console. Re-insert the key in the
console.
4 - If the problem persists, contact the after-sales service team
(see the last page of this manual).
The displays on the console stay lit up when you remove the
key from the console:
The console is fitted with a demo mode, designed to be used
when the treadmill is displayed in store. If the displays stay lit
up when you remove the key from the console, demo mode is
probably switched on. To switch off the demo mode, press and
hold the «STOP» button for a few seconds. If the displays are
still lit, refer to the INFORMATION MODE paragraph to switch off
demo mode.
The belt slows down when you walk on it:
1 - If you need an extension cable, only use a 1 mm² 3 conductor
cable that is no longer than 1.5m.
2 - If the belt is over-tightened, treadmill performance may be
affected and the belt may become damaged. Remove the
key and UNPLUG THE POWER CABLE. Using the hex key, turn
both roller bolts anticlockwise a quarter turn. When the belt
is correctly tightened, you should be able to raise each edge
of the moving belt 2 or 3 cm above the walking platform.
Be sure to keep the treadmill belt centred. Then, plug in the
power cable, insert the key and turn on the treadmill for a few
minutes. Repeat the process until the moving belt is correctly
tightened.
3 - If the problem persists, contact the after-sales service team
(see the last page of this manual).
The incline on the treadmill doesn’t change properly:
With the key inserted in the console, press on one of the incline
keys. When changing the incline, remove the key from the
console. After a few seconds, re-insert the key. The treadmill will
automatically lift itself up to the maximum incline and the return
to minimum level. In doing so, the incline system will recalibrate.
Motor noise when switching on the treadmill:
If the treadmill was switched off during an incline phase,
switching it on will generate automatic calibration of the incline
system. This will result in the motor making a noise without the
belt moving and the display of 2 bars on the control screen. The
running platform will automatically rise up to its maximum level
before coming down again. You can then use the treadmill as
normal.
