Dontek AQUATEK - Page 7

PUMP
PRIMING
&
CONNECTION
Reltech
P
[485]
/
Oasis
V
Series
Turning
Off
Priming
a]
Quickly
press
the
'stop'
button
three times.
b]
The
display
will
show
'P
Of
when
priming
is turned
off.
Turning
On
485
Communication
a]
Hold the
'stop'
button
for
10
secs.
b]
The
display
will
show
e.g.
'P
5'
[to
select
priming
time
in
minutes].
Press
'set'
button
to
move
to next.
c]
The
display
will
show
e.g.
'2400'
[to
select
priming
speed
in
RPM],
Press
'set'
button
to
move
to next.
d]
The
display
will
show
'Rb
Of.
Press
Up
or
Down
button
to
change
to
'Rb
On'.
Press
'set'
button
to
confirm.
e]
When communication
with
Aquatek
is
successful,
the
display
will
show
'
----
'.
Pentair enviroMAX
1500
Turning
Off
Priming
a]
Press
the
'Start
/
Stop'
button
to start
the
pump.
b]
The
display
will
alternate
between
'Pri'
and
'2800'
and
'04:59'
to
show
priming
at
2800
RPM
for
5mins.
c]
Press
the
'-'
to turn
the
priming
speed
down;
when
it
reaches below
1700,
priming
is turned
off.
d]
The
display
will
then
alternate
between
'Pri'
and
'Off'.
Note: External control
must
be
off.
Turning
On
External
Control
a]
Stop
the
pump
by
pressing
the
'Start
/
Stop'
button.
b]
Hold the
'Start
/
Stop'
button
for
~5
seconds.
c]
The
light
next to
'Ext.
Control
Only'
will
be
lighted
green.
d]
Press
the
'Start
/
Stop'
button.
e]
The
light
next to
'Start
/
Stop'
will
be
lighted
green.
Pentair
VS/F
Turning
Off
Priming
a]
Disconnect
the
RS-485
communication cable
from
the
pump.
b]
On
the
pump
control
module,
press
Menu
and
use
the
Arrow
buttons
to
scroll
and
select
"Priming".
c]
Use
the
Arrow
buttons
to
select
"Disabled",
then
press
the
Back
button
to
exit the
menu.
d]
Re-install the communication cable
to
the
pump.
Turning
On
External
Control
a]
Press
the
Menu
button,
use
the
Up
or
Down
arrow
to
scroll
to
Ext
Ctrl
and
press
Select.
b]
"Program
1"
will
be
displayed
and
press
Select
to enter.
c]
"Operation
Mode"
will
be
displayed,
press
Select
and
use
the
Up
or
Down
buttons
to
choose between
"Enabled"
or
"Pump
Off",
press
Save.
Note:
the
program
must
be enabled
to
proceed
further
into the
menu.
d]
Use
the
Up
or
Down
arrow
to
scroll
to
"Set
Type"
and
press
Select.
e]
Use
the
Up
or
Down
arrow
to
choose between
"Speed"
or
"Flow"
settings
and
press
Save.
f]
Use
the
Up
or
Down
arrow
to
scroll
to
"Set
Speed/Flow"
[depending
on
what
was
chosen
in
the
previous step],
press
Select
and then
use
the
Up
&
Down
arrows
to
adjust
the
speed/flow
settings
to
what
is
required
&
press
Save.
g]
There is
no
need
to set
a
"Stop
Delay"
so
press
the
Save
button
to
save
your
settings
and then
press
Back.
This
will
allow
you
to set
"Program
2".
h]
Use
the
Up
or
Down
arrow
to
scroll
to
"Program
2"
and
repeat steps
b]
to
g]
for
programs
2
to
4.
AQUATEK
User
Manual
VI.
2
[00E].docx
