2
1. GENERAL INFORMATION
Swing-4000 electromechanical linear operator is designed to automate a two-wing swing gate with rigid frame.
Operator body consists of two silumin parts, in which the gear motor and the lead screw are located.
Worm gear and planetary reduction gear form a self-locking system that provides mechanical locking of the gate leaf when the
motor is switched off. A convenient and safe release system allows you to manually open or close the gate leaf in case of power
outage or control unit malfunction. The automatic system is operated by a remote control unit in a shockproof sealed housing.
1.1. Specifications
GENERAL INFORMATION
Characteristics Value
Power supply 220–240 V / 50, 60 Hz
Power consumption 140 W
Consumed current 1,8 А
Speed 1,8 sm/sec
Maximum leaf length 4 m
Maximum leaf weight 400 kg
Temperature protection 150 °C
Cover protection class IP44
Intensity 50 %
Operating temperature -20…+55 °C
Gate leaf length, m Gate leaf weight, kg
2,5 400
3 350
3,5 300
4 250
Operating range
1.2. Carton inventory
After receiving the device, it must be unpacked and inspected for damage. In case of any defects, please contact the supplier
of the device.
The operator components included in the standard package are listed in the following table.
# Name Qty
1 Operator 2 pcs (left/right)
2 Control unit* 1 pc
3 Key-switch* 1 pc
4 Photocells* 1 pair
5 Signal lamp* 1 pc
6 Release key 2 pcs
7 Rear bracket 2 pcs
8 Front bracket 2 pcs
9 Hardware set 2 pcs
10 Owner’s manual 1 pc
*optional accessories (not provided)
