OPERATOR DESIGN
3. OPERATOR DESIGN
4. INSTALLATION
4.1. Tools
1. Set of spanners
2. Set of slotted and cross screwdrivers
3. Set of drills for metal
4. Set of drills for concrete
5. Pliers
6. Hacksaw for metal
7. Electric drill
8. Tape measure (folding rule)
1. Motor
2. Power cable
3. Rear bracket
4. Front bracket
5. Housing
6. Limit switches
1
4
5
6
3
2
1175
640
200
90
90
535
Unit: mm

DoorHan SWING-4000 Specifications

General

Brand	DoorHan
Model	SWING-4000
Category	Gate Opener
Language	English
