2358-065-L-7-16
2
SECTION 1 - TRACKER EXPANSION BOARD INTRODUCTION
Use this manual for Tracker Expansion Board 2358-010 Rev B or higher.
The Model 2358 Tracker Expansion Board allows you to expand the number of access points that the models 1833, 1835, 1837
and 1838 multi-door access controller PC Programmable Entry Systems can control, up to a maximum of 24. One tracker
expansion board is required for each access point. Tracker expansion boards will interface with a variety of wiegand devices
including card readers, RF transmitters, digital keypads, etc. The tracker expansion board will also report gate operator data
from DoorKing intelligent gate operators that have Gate Tracker outputs. In addition to these features, the tracker expansion
boards can also monitor the status of a door, report door ajar and forced entry conditions, sound local alarms, activate a
building alarm system, and has request to exit inputs.
Prior to beginning the installation, we suggest that you become familiar with the instructions, illustrations, and wiring
guidelines in this manual. This will help insure that your installation is performed in an efficient and professional manner.
The proper installation is an extremely important and integral part of the overall access control system. Check all local building
ordinances and building codes prior to installion. Be sure your installation is in compliance with local codes.
IMPORTANT Wireless installation of the access control system and tracker expansion boards will vary
from the HARDwire installation illustrated in this manual, see the instructions in the wireless kits for
wireless installation.
To utilize the tracker expansion board(s), DoorKing Remote Account Manager for Windows software, V 5.3 or higher is required to be
installed on the user supplied PC. The chart below is to assist you in determining if you have the proper access control system and gate
operators to utilize the tracker expansion board.
Model Control Board
Access Control Systems
1833, 1835, 1837, *1838
183x-010 Series
1601, 1602, 1603 Barrier
Model
1601-010
Control Board
Gate Operators
1150 Overhead
4402-010
9200, 9500 Slide
4404-010
6500 Swing, 9000 Slide
4405-010
6050, 6100, 6300 Swing
4502-010
9100, 9150 Slide
4602-010
1.1 General Information
• Expands the control capability of selected DoorKing access control systems to manage up to 24 additional access points.
• Provides power and wiegand inputs for almost any wiegand access control device (Card reader, RF receiver, digital keypad etc.). Board
may power two card readers in parallel if required. For example: an entry and exit card reader on a single door.
• Can be used to provide a variety of door monitoring functions, such as sounding an alarm, or activating a building alarm system when
the door is forced or held open.
• Provides a request to exit input (free exit).
• Provides three programmable relay outputs.
• Hold Open Feature unlocks individual doors (or holds open individual gates) when commanded from the system software.
• Monitors transactions from DoorKing intelligent gate operators. Can monitor slide, swing or overhead gate operators and the
parking gate operator (barrier) in PAMS type applications.
• Optional Wireless kit available to connect tracker expansion board(s) to an access control system wirelessly. Maximum distances
between the access control system and tracker expansion boards will vary from the HARD wire run distances illustrated in this manual,
see the instruction manuals with the wireless kits for the correct distances between the hardware.
* 1838 Multi-Door Access Controller ONLY. NOT for use with 1838 Access Plus.
