Doosan AD158TI User Manual

HY-DP-MANUAL-001 10
No.
Pin Description
Notes
No.
Pin Description
Notes
1
Exhaust Gas Temperature
Sensor 1 (+)
-
19
Spare Analog Input 3
-
2
Engine Water Temperature
Sensor
-
20
Pickup Sensor (+)
-
3
Engine Oil Pressure Sensor
-
21
-
-
4
*Engine Oil Temperature Sensor
-
22
-
-
5
*Boost Air Pressure Sensor
-
23
GND
Sensor
6
*Fuel Level Sensor
-
24
Valve Out
Valve
Control
Signal
7
Spare Analog Input 2
-
25
Exhaust Gas Temperature
Sensor 2 (+)
-
8
Spare Analog Input 4
-
26
Exhaust Gas Temperature
Sensor 2 (-)
-
9
Spare Digital Input 1
-
27
-
-
10
-
-
28
-
-
11
Fuel Leakage Switch
-
29
-
-
12
GND
Sensor
30
-
-
13
Exhaust Gas Temperature
Sensor 1 (-)
-
31
-
-
14
-
-
32
-
-
15
Gearbox Oil Pressure Sensor
-
33
-
-
16
*Engine Water Level Sensor
-
34
-
-
17
*Boost Air Temperature Sensor
-
35
GND
Sensor
18
Spare Analog Input 1
-
-
-
-
[Fig. 3-4]
3.3.2 Signal Connector
[Table 3-4]
* Sensor for IMO Tier 3
3. Part Names, Operation and Settings
