Operation Section
-43-
Circuit Breaker
Typical Example LP Engine Truck
Circuit Breaker - Protects the main electrical
circuits. To reset the circuit breaker, push the
button in. Located in the engine compartment.
Tilt Steering Column
To adjust the steering column, push down the knob(1),
and move the steering column to the desired position,
then release the knob(1).
Electrical Disconnect Switch (If
Equipped)
1. ON-Connects the battery for electrical power to all
electrical circuits.
2. OFF-Disconnects the battery from all electrical circuits.
Seat
NOTE: Seat arrangements may vary. Basic operation
will be similar.
Seat adjustment should be checked at the beginning of
each shift and when operators change.
Lock the seat into position before operating, to prevent
an unexpected seat change.
Adjust seat to allow full brake pedal travel with
operator’s back against seat back.
NOTE: The seat can only be correctly adjusted with the
operator fully seated.
1
