Specifications
CHARACTERISTICS
TIER-Ⅱ
1 Manufacturer DOOSAN DOOSAN
2 MODEL
G50S-5 G60S-5
3 Capacity at rated load center kg 5000 6000
4 Load center distance mm 600 600
5 Power type electric,diesel,gasoline,LPG LPG LPG
6 Operator type stand-on, rider-seated rider-seated rider-seated
7 Tire type c=cushion, p=pneumatic p p
8 Wheels(x=driven) number, front/rear 4/2 4/2
DIMENSIONS
9 Lift with STD maximum fork height with rated load mm 3000 3000
10 two stage mast free lift mm 205 205
13 Forks
thickness x width x length mm 60x150x1200 60x180x1200
fork spacing(minimum x maximum) mm 350x2032 410x2032
14 Tilt of mast forward / backward deg 15/10 15/10
15
Overall
dimensions
length to face of forks mm 3507 3568
16 width mm 2108 2108
17 mast lowered height mm 2500 2500
18 mast extended height mm 4340 4340
19 overhead guard height mm 2455 2455
20 seat height mm 1333 1333
21 Turning radius (minimum outside)
mm 3301 3331
22 Load moment constant mm 632 632
23 90 stacking aisle add load length and clearance mm 3924 3958
23a 90 intersecting aisle mm 2990 3020
PERFORMANCE
24
Speed
travel, loaded/unloaded km/h 24.0/25.4 23.8/25.4
25 lift, loaded/unloaded mm/s 380/410 380/410
26 lowering, loaded/unloaded mm/s 490/460 490/460
28 Drawbar pull at 1.6 km/h, loaded kg 5010 4990
30 Gradeability at 1.6 km/h, loaded % 40.9 35.5
WEIGHT
32 Total weight unloaded kg 8235 8905
33 Axle load with loaded, front/rear kg 11840/1395 13260/1645
34 without loaded, front/rear kg 4100/4135 3975/4930
CHASSIS
35
Tires
number of front/rear 4/2 4/2
36 size, front 8.25x15-14PR
8.25x15-14PR
37 size, rear 8.25x15-14PR
8.25x15-14PR
38 Wheel base mm 2250 2250
39 Tread width front/rear mm 1584/1550 1584/1550
40
Ground clearance
loaded, at the lowest point mm 176 176
41 loaded, at center of wheelbase mm 205 205
42
Brakes
service brake foot/hydraulic
foot/hydraulic
43 parking brake
hand/mechanic
al
hand/mechanic
al
DRIVE
45 Battery voltage/capacity v/ah 12/75 12/75
49
Engine
manufacturer/model G643E(TIER-2)
G643E(TIER-2)
50 rated output (at rpm) KW(hp)/rpm
69.0/2450 69.0/2450
51 max. torque N-m(lb-ft)/rpm
301/1400 301/1400
52 cycle/cylinders/displacement cc 4/6/4294 4/6/4294
55
Transmission
type
56 no. speeds forward/reverse Power Shift Power Shift
