Specifications
CHARACTERISTICS
3 Speed, Interim TIER-Ⅳ
1 Manufacturer DOOSAN DOOSAN
2 MODEL
D50S-5 D60S-5
3 Capacity at rated load center kg 6000
4 Load center distance mm 600
5 Power type electric,diesel,gasoline,LPG diesel
6 Operator type stand-on, rider-seated rider-seated
7 Tire type c=cushion, p=pneumatic p
8 Wheels(x=driven) number, front/rear 4/2
DIMENSIONS
9 Lift with STD
maximum fork hei
ht with rated
load
mm 3000
10 two stage mast free lift mm 205
13 Forks
thickness x width x length mm 60x180x1200
fork spacing(minimum x maximum) mm 410x2032
14 Tilt of mast forward / backward deg 15/10
15
Overall
dimensions
length to face of forks mm 3568
16 width mm 2108
17 mast lowered height mm 2500
18 mast extended height mm 4340
19 overhead guard height mm 2455
20 seat height mm 1333
21 Turning radius (minimum outside)
mm 3331
22 Load moment constant mm 632
23 90 stacking aisle add load length and clearance mm 3958
23a 90 intersecting aisle mm 3020
PERFORMANCE
24
Speed
travel, loaded/unloaded km/h 30/34
25 lift, loaded/unloaded mm/s 500/550
26 lowering, loaded/unloaded mm/s 500/450
28 Drawbar pull at 1.6 km/h, loaded kg 5379
30 Gradeability at 1.6 km/h, loaded % 38
WEIGHT
32 Total weight unloaded kg 9240
33 Axle load with loaded, front/rear kg 13585/1655
34 without loaded, front/rear kg 4300/4940
CHASSIS
35
Tires
number of front/rear 4/2
36 size, front 8.25x15-14PR
37 size, rear 8.25x15-14PR
38 Wheel base mm 2250
39 Tread width front/rear mm 1584/1550
40
Ground clearance
loaded, at the lowest point mm 176
41 loaded, at center of wheelbase mm 205
42
Brakes
service brake foot/hydraulic
43 parking brake hand/mechanical
DRIVE
45 Battery voltage/capacity v/ah 24/75
49
Engine
manufacturer/model Kubota/V3800
50 rated output (at rpm) KW/rpm 82/2400
51 max. torque N-m/rpm 375.1/1500
52 cycle/cylinders/displacement cc 4/4/3769
55
Transmission
type
56 no. speeds forward/reverse Full Auto
